NETWORK Technology GSM / HSPA / LTE

2G bands GSM 850 / 900 / 1800 / 1900

3G bands HSDPA 850 / 900 / 1900 / 2100 – E6603, E6653

4G bands LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 17(700), 20(800), 28(700), 38(2600), 40(2300) – E6603, E6653

Speed HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps (E6603), LTE-A Cat6 300/50 Mbps (E6653)

GPRS Up to 107 kbps

EDGE Up to 296 kbps

LAUNCH Announced 2015, September

Status Available. Released 2015, October

BODY Dimensions 146 x 72 x 7.3 mm (5.75 x 2.83 x 0.29 in)

Weight 154 g (5.43 oz)

Build Front/again glass, aluminum body

SIM Nano-SIM

– IP68 licensed – mud/water proof (as much as 1.5m for 30 minutes)

DISPLAY Type IPS LCD capacitive touchscreen, 16M colours

Size 5.2 inches, 73.2 cm2 (~69.6% screen-to-body ratio)

Resolution 1080 x 1920 pixels, 16:9 ratio (~428 ppi density)

Multitouch Yes, as much as 10 fingers

Protection Scratch-resistant glass, oleophobic coating

– Triluminos show

– X-Reality Engine

PLATFORM OS Android 5.1.1 (Lollipop), upgradable to 7.1.1 (Nougat)

Chipset Qualcomm MSM8994 Snapdragon 810

CPU Octa-core (4×1.5 GHz Cortex-A53 & 4×2.0 GHz Cortex-A57)

GPU Adreno 430

MEMORY Card slot microSD, as much as 256 GB (devoted slot)

Internal 32 GB, 3 GB RAM

CAMERA Primary 23 MP (f/2.0, 24mm, 1/2.3"), part detection autofocus, LED flash,

Features Geo-tagging, contact focus, face detection, HDR, panorama

Video 2160p@30fps, 1080p@60fps, 720p@120fps, HDR,

Secondary 5.1 MP, f/2.4, 1080p, HDR

SOUND Alert varieties Vibration; MP3, WAV ringtones

Loudspeaker Yes, with stereo audio system

3.5mm jack Yes

– 24-bit/192kHz audio

– Active noise cancellation with devoted mic

COMMS WLAN Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot

Bluetooth 4.1, A2DP, aptX

GPS Yes, with A-GPS, GLONASS/ BDS (market dependant)

NFC Yes

Radio FM radio, RDS

USB microUSB 2.0 (MHL 3 TV-out), USB Host

FEATURES Sensors Fingerprint (side-mounted; EU mannequin solely), accelerometer, gyro, proximity, compass, barometer

Messaging SMS(threaded view), MMS, Email, IM, Push Email

Browser HTML5

– Fast battery charging (Quick Charge 2.0)

– ANT+ help

– Xvid/MP4/H.265 participant

– MP3/eAAC+/WAV/Flac participant

– Document viewer

– Photo/video editor

BATTERY Non-removable Li-Ion 2900 mAh battery
